SURS8205T3G
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 50V 2A Automotive 2-Pin SMB T/R
PDF
/
Buying Options
Total Price: USD $1.3
Unit Price: USD $1.2996
≥1 USD $1.2996
≥10 USD $1.06685
≥100 USD $1.0336
≥500 USD $1.00035
≥1000 USD $0.9671
≥1000 USD $0.8664
Inventory: 41876
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Surface Mount YES
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -60°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position DUAL
Terminal Form J BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
Reference Standard AEC-Q101
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 2μA @ 50V
Voltage - Forward (Vf) (Max) @ If 940mV @ 2A
Forward Current 2A
Operating Temperature - Junction -60°C~175°C
Output Current-Max 2A
Application HIGH VOLTAGE ULTRA FAST RECOVERY POWER
Halogen Free Halogen Free
Forward Voltage 940mV
Max Reverse Voltage (DC) 50V
Average Rectified Current 2A
Number of Phases 1
Reverse Recovery Time 30 ns
Peak Reverse Current 2μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 50A
Max Forward Surge Current (Ifsm) 50A
Dimensions
Height 2.09mm
Length 4.6mm
Width 3.95mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
