SB07-03P-TD-E
RoHS
/
Package TO-243AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Tape & Reel (TR) Surface Mount Schottky Single Diode Schottky 26pF @ 10V 1MHz 700mA 10ns 30V
PDF
/
Buying Options
Total Price: USD $1.57
Unit Price: USD $1.57225
≥1 USD $1.57225
≥10 USD $1.2901
≥100 USD $1.2502
≥500 USD $1.20935
≥1000 USD $1.16945
Inventory: 1234
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e6
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Bismuth (Sn/Bi)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature HIGH RELIABILITY
Terminal Form FLAT
Pin Count 3
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 80μA @ 15V
Voltage - Forward (Vf) (Max) @ If 550mV @ 700mA
Case Connection CATHODE
Forward Current 700mA
Max Reverse Leakage Current 80μA
Operating Temperature - Junction -55°C~125°C
Max Surge Current 5A
Output Current-Max 0.7A
Max Reverse Voltage (DC) 30V
Average Rectified Current 700mA
Reverse Recovery Time 10 ns
Max Repetitive Reverse Voltage (Vrrm) 30V
Capacitance @ Vr, F 26pF @ 10V 1MHz
Peak Non-Repetitive Surge Current 5A
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
