UES2602
RoHS
/
Package TO-204AA, TO-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 100V 30A 3-Pin(2+Tab) TO-3
PDF
/
Inventory: 2992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Peak Non-Repetitive Surge Current 400A
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Reverse Current 20μA
Reverse Recovery Time 35 ns
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 100V
Forward Voltage 930mV
Application EFFICIENCY
Operating Temperature - Junction -55°C~175°C
Forward Current 30A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 930mV @ 15A
Current - Reverse Leakage @ Vr 20μA @ 100V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 2
JESD-30 Code O-MBFM-P2
Pin Count 2
Terminal Form PIN/PEG
Terminal Position BOTTOM
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish TIN LEAD
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Discontinued
Pbfree Code no
JESD-609 Code e0
Published 1997
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case TO-204AA, TO-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
