JANTX1N6641
RoHS
/
Package D, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 50V 300MA AXIAL
PDF
/
Inventory: 2776
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Lead, Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case D, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Bulk
Published 1999
Series Military, MIL-PRF-19500/609
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature METALLURGICALLY BONDED
HTS Code 8541.10.00.70
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
Reference Standard MIL-19500/609D
Qualification Status Qualified
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 100μA @ 50V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 300mA
Case Connection ISOLATED
Forward Current 300mA
Operating Temperature - Junction -65°C~175°C
Output Current-Max 0.3A
Current - Average Rectified (Io) 300mA DC
Reverse Recovery Time 5ns
Max Repetitive Reverse Voltage (Vrrm) 50V
JEDEC-95 Code DO-35
Reverse Current-Max 0.1μA
Compliance
RoHS Status Non-RoHS Compliant
