UF4007-AP
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GPP ULT FAST 1A DO-41
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Capacitance @ Vr, F 10pF @ 4V 1MHz
Rep Pk Reverse Voltage-Max 1000V
Reverse Recovery Time 75ns
Current - Average Rectified (Io) 1A
Voltage - DC Reverse (Vr) (Max) 1000V
Output Current-Max 1A
Operating Temperature - Junction -55°C~125°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.7V @ 40V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PALF-W2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case DO-204AL, DO-41, Axial
Mounting Type Through Hole
