S2G-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 400V 2A DO214AA
PDF
/
Buying Options
Total Price: USD $0.05
Unit Price: USD $0.04675
≥1 USD $0.04675
≥10 USD $0.038274
≥100 USD $0.034035
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Pk Forward Current-Max 50A
Rep Pk Reverse Voltage-Max 400V
Reverse Recovery Time 2μs
Number of Phases 1
Current - Average Rectified (Io) 2A
Voltage - DC Reverse (Vr) (Max) 400V
Application GENERAL PURPOSE
Output Current-Max 2A
Operating Temperature - Junction -55°C~150°C
Voltage - Forward (Vf) (Max) @ If 1.15V @ 2A
Current - Reverse Leakage @ Vr 10μA @ 400V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-C2
Pin Count 2
Base Part Number S2G
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 1996
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
