S1B-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 100V 1A DO214AA
PDF
/
Inventory: 9079
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 2
JESD-30 Code R-PDSO-C2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 100V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Operating Temperature - Junction -55°C~150°C
Output Current-Max 1A
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 1A
Reverse Recovery Time 2μs
Rep Pk Reverse Voltage-Max 100V
Capacitance @ Vr, F 12pF @ 4V 1MHz
Non-rep Pk Forward Current-Max 30A
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Compliance
RoHS Status ROHS3 Compliant
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
