RA356-BP
RoHS
RoHS compliant
RoHS compliantPackage RA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
RA Surface Mount Standard SINGLE Diode Standard 100pF @ 4V 1MHz 35A 800V -55C~150C
PDF
/
Inventory: 4655
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Non-rep Pk Forward Current-Max 500A
Capacitance @ Vr, F 100pF @ 4V 1MHz
Rep Pk Reverse Voltage-Max 800V
Number of Phases 1
Current - Average Rectified (Io) 35A
Voltage - DC Reverse (Vr) (Max) 800V
Output Current-Max 35A
Operating Temperature - Junction -55°C~150°C
Voltage - Forward (Vf) (Max) @ If 1V @ 35A
Current - Reverse Leakage @ Vr 5μA @ 800V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-XEDB-N2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position END
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case RA
Mounting Type Surface Mount
