MUR4100-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 4A DO201AD
PDF
/
Inventory: 3871
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 1996
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MUR4100
Pin Count 2
JESD-30 Code O-XALF-W2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 1000V
Voltage - Forward (Vf) (Max) @ If 1.85V @ 4A
Case Connection ISOLATED
Operating Temperature - Junction -55°C~150°C
Output Current-Max 4A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 1000V
Current - Average Rectified (Io) 4A
Number of Phases 1
Reverse Recovery Time 75ns
Rep Pk Reverse Voltage-Max 1000V
Non-rep Pk Forward Current-Max 150A
Compliance
RoHS Status RoHS Compliant
