MBRX120LSF-TP
RoHS
RoHS compliant
RoHS compliantPackage SOD-123F
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY SOD-123FL
PDF
/
Inventory: 1597
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Rep Pk Reverse Voltage-Max 20V
Current - Average Rectified (Io) 1A
Voltage - DC Reverse (Vr) (Max) 20V
Output Current-Max 1A
Operating Temperature - Junction -65°C~125°C
Voltage - Forward (Vf) (Max) @ If 450mV @ 1A
Current - Reverse Leakage @ Vr 400μA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-F2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position DUAL
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SOD-123F
Mounting Type Surface Mount
