1N5399-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GPP 1.5A DO-15
PDF
/
Inventory: 9284
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 1996
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code O-PALF-W2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Non-rep Pk Forward Current-Max 50A
Capacitance @ Vr, F 20pF @ 4V 1MHz
Rep Pk Reverse Voltage-Max 1000V
Number of Phases 1
Current - Average Rectified (Io) 1.5A
Voltage - DC Reverse (Vr) (Max) 1000V
Application GENERAL PURPOSE
Output Current-Max 1.5A
Operating Temperature - Junction -55°C~150°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.1V @ 40V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Compliance
RoHS Status RoHS Compliant
