1N5396-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GPP 1.5A DO-15
PDF
/
Inventory: 6119
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Non-rep Pk Forward Current-Max 50A
Capacitance @ Vr, F 20pF @ 4V 1MHz
Rep Pk Reverse Voltage-Max 500V
Number of Phases 1
Current - Average Rectified (Io) 1.5A
Voltage - DC Reverse (Vr) (Max) 500V
Application GENERAL PURPOSE
Output Current-Max 1.5A
Operating Temperature - Junction -55°C~150°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.1V @ 40V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code O-PALF-W2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature LOW LEAKAGE CURRENT
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
