1N4934-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GPP FAST 1A DO-41
PDF
/
Inventory: 6666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case DO-204AL, DO-41, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 1996
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature METALLURGICALLY BONDED
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code O-PALF-W2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Voltage - Forward (Vf) (Max) @ If 1.3V @ 40V
Case Connection ISOLATED
Operating Temperature - Junction -55°C~150°C
Output Current-Max 1A
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 1A
Reverse Recovery Time 200ns
Rep Pk Reverse Voltage-Max 100V
Capacitance @ Vr, F 15pF @ 4V 1MHz
Non-rep Pk Forward Current-Max 30A
Compliance
RoHS Status RoHS Compliant
