1F2G-TP
RoHS
RoHS compliant
RoHS compliantPackage R-1, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GPP FAST 1A R-1
PDF
/
Inventory: 6310
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case R-1, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8541.10.00.80
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code O-PALF-W2
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Voltage - Forward (Vf) (Max) @ If 1.3V @ 40V
Case Connection ISOLATED
Operating Temperature - Junction -55°C~150°C
Output Current-Max 1A
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 1A
Reverse Recovery Time 150ns
Rep Pk Reverse Voltage-Max 100V
Capacitance @ Vr, F 12pF @ 4V 1MHz
Compliance
RoHS Status RoHS Compliant
