DSS2-40BB
RoHS
/
Package DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Schottky 40V 4A 2-Pin SMB
PDF
/
Inventory: 4214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Operating Temperature - Junction -55°C~150°C
Output Current-Max 2A
Application POWER
Forward Voltage 500mV
Max Reverse Voltage (DC) 40V
Average Rectified Current 2A
Number of Phases 1
Peak Non-Repetitive Surge Current 110A
Voltage - Forward (Vf) (Max) @ If 420mV @ 2A
Current - Reverse Leakage @ Vr 500μA @ 40V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form C BEND
Terminal Position DUAL
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW NOISE
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2003
Packaging Tape & Reel (TR)
Compliance
RoHS Status RoHS Compliant
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
