DSS10-01AS
RoHS
/
Package TO-263-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 10A TO263AB
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.602069
≥1 USD $2.602069
≥10 USD $2.454784
≥100 USD $2.315833
≥500 USD $2.184747
≥1000 USD $2.061081
Inventory: 9476
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Peak Non-Repetitive Surge Current 120A
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 100V
Forward Voltage 840mV
Application POWER
Max Surge Current 120A
Max Reverse Leakage Current 300μA
Case Connection CATHODE
Diode Type RECTIFIER DIODE
Element Configuration Single
Power Dissipation-Max 90W
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Technology SCHOTTKY
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY, LOW NOISE, FREEWHEELING DIODE
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-263-3
Mount Surface Mount
