DSEP60-03A
RoHS
/
Package TO-247-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 300V 60A TO247
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 483
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Non-rep Pk Forward Current-Max 700A
Reverse Recovery Time 30 ns
Number of Phases 1
Average Rectified Current 60A
Max Reverse Voltage (DC) 300V
Forward Voltage 1.71V
Application HYPERFAST SOFT RECOVERY
Operating Temperature - Junction -55°C~175°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.71V @ 60A
Current - Reverse Leakage @ Vr 650μA @ 300V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 35
Peak Reflow Temperature (Cel) 260
Technology AVALANCHE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, SNUBBER DIODE
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series HiPerFRED?
Published 2003
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case TO-247-2
Mounting Type Through Hole
Mount Through Hole
