DSEP29-03A
RoHS
/
Package TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 300V 30A TO220AC
PDF
/
Inventory: 1781
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
Published 2005
Series HiPerFRED?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Through Hole
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Additional Feature SNUBBER DIODE, FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Technology AVALANCHE
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 35
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 170W
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 300V
Voltage - Forward (Vf) (Max) @ If 1.26V @ 30A
Case Connection CATHODE
Forward Current 30A
Operating Temperature - Junction -55°C~175°C
Max Surge Current 300A
Application GENERAL PURPOSE
Forward Voltage 930mV
Max Reverse Voltage (DC) 300V
Average Rectified Current 30A
Number of Phases 1
Reverse Recovery Time 30 ns
Peak Reverse Current 250μA
Max Repetitive Reverse Voltage (Vrrm) 300V
Peak Non-Repetitive Surge Current 300A
Reverse Voltage 300V
Max Forward Surge Current (Ifsm) 300A
Recovery Time 30 ns
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
