DSEP15-06AS-TRL
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
POWER DIODE DISCRETES-FRED TO-26
PDF
/
Inventory: 9034
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Active
Number of Terminations 2
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT,PD-CASE, SNUBBER DIODE
Technology AVALANCHE
Terminal Position SINGLE
Terminal Form GULL WING
Reference Standard IEC-60747
JESD-30 Code R-PSSO-G2
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Power Dissipation-Max 95W
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 100μA @ 600V
Voltage - Forward (Vf) (Max) @ If 2.04V @ 15A
Case Connection CATHODE
Operating Temperature - Junction -55°C~175°C
Output Current-Max 15A
Application FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 15A
Number of Phases 1
Reverse Recovery Time 35ns
Rep Pk Reverse Voltage-Max 600V
Capacitance @ Vr, F 12pF @ 400V 1MHz
Non-rep Pk Forward Current-Max 110A
Reverse Current-Max 100μA
