DSEI25-06AS-TRL
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
POWER DIODE DISCRETES-FRED TO-26
PDF
/
Inventory: 7919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Reference Standard IEC-60747
JESD-30 Code R-PSSO-G2
Operating Temperature (Max) 125°C
Number of Elements 1
Configuration SINGLE
Power Dissipation-Max 105W
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 100μA @ 600V
Voltage - Forward (Vf) (Max) @ If 1.31V @ 25A
Case Connection CATHODE
Operating Temperature - Junction -40°C~150°C
Output Current-Max 25A
Application SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 25A
Number of Phases 1
Reverse Recovery Time 50ns
Rep Pk Reverse Voltage-Max 600V
Capacitance @ Vr, F 20pF @ 400V 1MHz
Non-rep Pk Forward Current-Max 240A
Reverse Current-Max 100μA
Terminal Form GULL WING
Terminal Position SINGLE
Technology AVALANCHE
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, PD-CASE
Number of Terminations 2
Part Status Active
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
