DSA15IM200UC
RoHS
/
Package TO-252-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
PDF
/
Buying Options
Total Price: USD $9.47
Unit Price: USD $9.47245
≥1 USD $9.47245
≥10 USD $7.77195
≥100 USD $7.5297
≥500 USD $7.2865
≥1000 USD $7.0433
Inventory: 1256
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Thermal Resistance @ Natural 2 °C/W
Forward Voltage-Max 0.78V
Non-rep Pk Forward Current-Max 80A
JEDEC-95 Code TO-252AA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 200V
Application SOFT RECOVERY
Case Connection CATHODE
Diode Type RECTIFIER DIODE
Configuration SINGLE
Number of Elements 1
Operating Temperature (Min) -55°C
Operating Temperature (Max) 175°C
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology SCHOTTKY
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY, LOW NOISE
ECCN Code EAR99
Number of Terminations 2
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case TO-252-3
Mount Surface Mount
