DSA15I45PA
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
IXYS SEMICONDUCTOR DSA15I45PA Small Signal Schottky Diode, Single, 45 V, 15 A, 630 mV, 140 A, 175 C
PDF
/
Buying Options
Total Price: USD $1.25
Unit Price: USD $1.249881
≥1 USD $1.249881
≥200 USD $0.498902
≥500 USD $0.483147
≥1000 USD $0.473957
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Forward Surge Current (Ifsm) 140A
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 500μA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 45V
Forward Voltage 910mV
Application SOFT RECOVERY
Operating Temperature - Junction -55°C~175°C
Forward Current 15A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 750mV @ 15A
Current - Reverse Leakage @ Vr 500μA @ 45V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY,FREEWHEELING DIODE, LOW NOISE
Min Operating Temperature -55°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2006
Packaging Tube
Physical
Diode Element Material SILICON
Weight 2.299997g
Number of Pins 2
Package / Case TO-220-2
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 28 Weeks
Alternative Model
