DS2-12A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1.2KV 3.6A AXIAL
PDF
/
Inventory: 3159
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2000
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Nickel (Ni)
Max Operating Temperature 180°C
Min Operating Temperature -40°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Technology AVALANCHE
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 2mA @ 1200V
Voltage - Forward (Vf) (Max) @ If 1.25V @ 7A
Case Connection ISOLATED
Max Reverse Leakage Current 2mA
Operating Temperature - Junction -40°C~180°C
Max Surge Current 120A
Application GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max) 1200V
Forward Voltage 1.25V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 3.6A
Number of Phases 1
Peak Non-Repetitive Surge Current 127A
Compliance
RoHS Status ROHS3 Compliant
