DGS10-025A
RoHS
/
Package TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 250V 12A TO220AC
PDF
/
Inventory: 5798
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Reverse Recovery Time-Max 0.013μs
JEDEC-95 Code TO-220AC
Number of Phases 1
Average Rectified Current 12A
Max Reverse Voltage (DC) 250V
Application GENERAL PURPOSE
Max Surge Current 20A
Operating Temperature - Junction -55°C~175°C
Max Reverse Leakage Current 1.3mA
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.5V @ 5A
Current - Reverse Leakage @ Vr 1.3mA @ 250V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 35
Peak Reflow Temperature (Cel) 260
HTS Code 8541.10.00.80
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2004
Packaging Tube
Physical
Diode Element Material GALLIUM ARSENIDE
Package / Case TO-220-2
Mounting Type Through Hole
Mount Through Hole
