DGS10-018AS
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 180V 15A TO263AB
PDF
/
Inventory: 4792
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Reverse Recovery Time-Max 0.013μs
Max Forward Surge Current (Ifsm) 20A
Max Repetitive Reverse Voltage (Vrrm) 180V
Peak Reverse Current 1.3mA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 180V
Forward Voltage 1.1V
Application GENERAL PURPOSE
Operating Temperature - Junction -55°C~175°C
Forward Current 15A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.1V @ 5A
Current - Reverse Leakage @ Vr 1.3mA @ 180V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
HTS Code 8541.10.00.80
Additional Feature HIGH SWITCHING SPEED
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2004
Packaging Tube
Physical
Diode Element Material GALLIUM ARSENIDE
Weight 1.59999g
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
