D770N20T
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
PDF
/
Inventory: 7293
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Max Forward Surge Current (Ifsm) 6kA
Forward Voltage-Max 1.76V
Non-rep Pk Forward Current-Max 6000A
Rep Pk Reverse Voltage-Max 2000V
Max Repetitive Reverse Voltage (Vrrm) 2kV
Number of Phases 1
Halogen Free Halogen Free
Application GENERAL PURPOSE
Output Current-Max 770A
Diode Type RECTIFIER DIODE
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 180°C
Qualification Status Not Qualified
JESD-30 Code O-CEDB-N2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position END
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
Physical
Diode Element Material SILICON
Surface Mount YES
