D1230N18T
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Rectifiers Rectifier Diode 1230A 1800V
PDF
/
Buying Options
Total Price: USD $120.63
Unit Price: USD $120.626056
≥1 USD $120.626056
≥10 USD $113.798161
≥100 USD $107.356758
≥500 USD $101.279963
≥1000 USD $95.54713
Inventory: 1405
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Max Forward Surge Current (Ifsm) 11.8kA
Forward Voltage-Max 1.77V
Reverse Voltage 1.8kV
Peak Non-Repetitive Surge Current 14.8kA
Max Repetitive Reverse Voltage (Vrrm) 1.8kV
Peak Reverse Current 50mA
Number of Phases 1
Halogen Free Halogen Free
Application GENERAL PURPOSE
Max Surge Current 11.8kA
Forward Current 1.23kA
Diode Type RECTIFIER DIODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position END
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 180°C
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
Physical
Diode Element Material SILICON
Number of Pins 2
Mount Screw
