SDT8A120P5Q-7D
RoHS
RoHS compliant
RoHS compliantPackage PowerDI? 5
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 120V 8A POWERDI5
PDF
/
Inventory: 4022
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case PowerDI? 5
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY
HTS Code 8541.10.00.80
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-F3
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 300μA @ 120V
Voltage - Forward (Vf) (Max) @ If 840mV @ 8A
Case Connection CATHODE
Operating Temperature - Junction -55°C~150°C
Output Current-Max 8A
Application FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 120V
Current - Average Rectified (Io) 8A
Number of Phases 1
Rep Pk Reverse Voltage-Max 120V
Non-rep Pk Forward Current-Max 150A
Reverse Current-Max 300μA
Compliance
RoHS Status ROHS3 Compliant
