SDT15150P5-13D
RoHS
RoHS compliant
RoHS compliantPackage PowerDI? 5
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Tape & Reel (TR) Surface Mount Schottky SINGLE Diode Schottky 860mV @ 15A 15A 150V -55C~150C
PDF
/
Inventory: 2920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 100μA
Non-rep Pk Forward Current-Max 250A
Rep Pk Reverse Voltage-Max 150V
Number of Phases 1
Current - Average Rectified (Io) 15A
Voltage - DC Reverse (Vr) (Max) 150V
Application FAST SOFT RECOVERY
Output Current-Max 15A
Operating Temperature - Junction -55°C~150°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 860mV @ 15A
Current - Reverse Leakage @ Vr 100μA @ 150V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
JESD-30 Code R-PDSO-F3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position DUAL
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case PowerDI? 5
Mounting Type Surface Mount
