SDM1U60P1-7
RoHS
RoHS compliant
RoHS compliantPackage POWERDI?123
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Schottky 60V 1A Surface Mount PowerDI? 123
PDF
/
Inventory: 7612
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Capacitance @ Vr, F 52pF @ 10V 1MHz
Rep Pk Reverse Voltage-Max 60V
Current - Average Rectified (Io) 1A
Voltage - DC Reverse (Vr) (Max) 60V
Output Current-Max 1A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 500mV @ 1A
Current - Reverse Leakage @ Vr 100μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Min) -55°C
Operating Temperature (Max) 150°C
JESD-30 Code R-PDSO-F2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series Automotive, AEC-Q101
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case POWERDI?123
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
