B380BE-13
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 80V 3A SMB
PDF
/
Inventory: 7039
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.80
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDSO-C2
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 150μA @ 80V
Voltage - Forward (Vf) (Max) @ If 790mV @ 3A
Operating Temperature - Junction -55°C~150°C
Output Current-Max 3A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 80V
Current - Average Rectified (Io) 3A
Number of Phases 1
Rep Pk Reverse Voltage-Max 80V
Capacitance @ Vr, F 105pF @ 4V 1MHz
Non-rep Pk Forward Current-Max 100A
Reverse Current-Max 150μA
Compliance
RoHS Status ROHS3 Compliant
