B360CE-13
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 3A SMC
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 15007
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 200μA
Non-rep Pk Forward Current-Max 80A
Capacitance @ Vr, F 110pF @ 4V 1MHz
Rep Pk Reverse Voltage-Max 60V
Number of Phases 1
Current - Average Rectified (Io) 3A
Voltage - DC Reverse (Vr) (Max) 60V
Application EFFICIENCY
Output Current-Max 3A
Operating Temperature - Junction -55°C~150°C
Voltage - Forward (Vf) (Max) @ If 650mV @ 3A
Current - Reverse Leakage @ Vr 200μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
JESD-30 Code R-PDSO-C2
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
