APD340VG-G1
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 40V 3A DO15
PDF
/
Inventory: 2324
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 500μA
Non-rep Pk Forward Current-Max 80A
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 40V
Voltage - DC Reverse (Vr) (Max) 40V
Application GENERAL PURPOSE
Output Current-Max 3A
Operating Temperature - Junction -50°C~125°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 500mV @ 3A
Current - Reverse Leakage @ Vr 500μA @ 40V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 125°C
JESD-30 Code O-PALF-W2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW NOISE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2014
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
