1N5818-B
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Schottky Diodes & Rectifiers 1.0A 30V
PDF
/
Inventory: 2557
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2.71mm
Length 4.7mm
Height 2.71mm
Technical
Natural Thermal Resistance 50 °C/W
Max Forward Surge Current (Ifsm) 25A
Peak Non-Repetitive Surge Current 25A
Capacitance @ Vr, F 110pF @ 4V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 30V
Peak Reverse Current 1mA
Average Rectified Current 1A
Max Reverse Voltage (DC) 30V
Forward Voltage 875mV
Output Current-Max 1A
Operating Temperature - Junction -65°C~125°C
Forward Current 1A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 550mV @ 1A
Current - Reverse Leakage @ Vr 1mA @ 30V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number 1N5818
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature LOW POWER LOSS, FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Published 2006
Packaging Bulk
Physical
Diode Element Material SILICON
Weight 310.002035mg
Number of Pins 2
Package / Case DO-204AL, DO-41, Axial
Mounting Type Through Hole
Mount Through Hole
