1N5402-B
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 200V 3A 2-Pin DO-201AD Bulk
PDF
/
Inventory: 7066
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Length 9.5mm
Height 5.3mm
Technical
Reverse Voltage (DC) 200V
Peak Non-Repetitive Surge Current 200A
Capacitance @ Vr, F 50pF @ 4V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 10μA
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 200V
Forward Voltage 1V
Application GENERAL PURPOSE
Output Current-Max 3A
Max Surge Current 200A
Operating Temperature - Junction -65°C~150°C
Forward Current 3A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1V @ 3A
Current - Reverse Leakage @ Vr 10μA @ 200V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number 1N5402
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Bulk
Physical
Diode Element Material SILICON
Weight 1.09999g
Number of Pins 2
Package / Case DO-201AD, Axial
Mounting Type Through Hole
Mount Through Hole
