CSD02060A
RoHS
/
Package TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 600V 3.5A TO220-2
PDF
/
Inventory: 5246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2
Number of Pins 2
Supplier Device Package TO-220-2
Technical
Packaging Tube
Published 2009
Series Zero Recovery?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Capacitance 120pF
Voltage - Rated DC 600V
Current Rating 2A
Polarity Standard
Element Configuration Single
Speed No Recovery Time > 500mA (Io)
Diode Type Silicon Carbide Schottky
Current - Reverse Leakage @ Vr 200μA @ 600V
Output Current 3.5A
Voltage - Forward (Vf) (Max) @ If 1.8V @ 2A
Forward Current 3.5A
Operating Temperature - Junction -55°C~175°C
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 3.5A
Max Reverse Voltage (DC) 600V
Average Rectified Current 3.5A
Reverse Recovery Time 0 s
Peak Reverse Current 200μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Capacitance @ Vr, F 120pF @ 0V 1MHz
Peak Non-Repetitive Surge Current 65A
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
