CDBA140SLR-HF
RoHS
/
Package DO-214AC, SMA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Tape & Reel (TR) Surface Mount Schottky SINGLE Diode Schottky 120pF @ 4V 1MHz 1A 40V -50C~150C
PDF
/
Inventory: 998
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Capacitance @ Vr, F 120pF @ 4V 1MHz
Average Rectified Current 1A
Max Reverse Voltage (DC) 40V
Current - Average Rectified (Io) 1A DC
Output Current-Max 1A
Max Surge Current 30A
Operating Temperature - Junction -50°C~150°C
Voltage - Forward (Vf) (Max) @ If 400mV @ 2A
Current - Reverse Leakage @ Vr 1mA @ 40V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
Base Part Number CDBA140
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2012
Packaging Tape & Reel (TR)
Physical
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
