CMSH2-100 TR13
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
PDF
/
Buying Options
Total Price: USD $4.31
Unit Price: USD $4.313
≥1 USD $4.313
≥10 USD $3.5397
≥100 USD $3.42855
≥500 USD $3.31835
≥1000 USD $3.2072
Inventory: 10004
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Forward Voltage-Max 0.85V
Non-rep Pk Forward Current-Max 50A
Rep Pk Reverse Voltage-Max 100V
Number of Phases 1
Application GENERAL PURPOSE
Output Current-Max 2A
Diode Type RECTIFIER DIODE
Configuration SINGLE
Number of Elements 1
Operating Temperature (Min) -65°C
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-C2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology SCHOTTKY
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1
Pbfree Code icon-pbfree yes
JESD-609 Code e3
Physical
Number of Terminals 2
Diode Element Material SILICON
Surface Mount YES
