CMPD1001 BK
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
PDF
/
Inventory: 5477
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Reverse Recovery Time-Max 0.05μs
Reverse Current-Max 0.1μA
Forward Voltage-Max 1.25V
Non-rep Pk Forward Current-Max 6A
Rep Pk Reverse Voltage-Max 90V
Output Current-Max 0.25A
Diode Type RECTIFIER DIODE
Power Dissipation-Max 0.35W
Configuration SINGLE
Number of Elements 1
Operating Temperature (Min) -65°C
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G3
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Rectifier Diodes
HTS Code 8541.10.00.70
Terminal Finish MATTE TIN (315)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1
Pbfree Code icon-pbfree yes
JESD-609 Code e3
Physical
Number of Terminals 3
Diode Element Material SILICON
Surface Mount YES
