VS-83CNQ080ASMPBF
RoHS
RoHS compliant
RoHS compliantPackage D-61-8-SM
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Schottky 100V 80A 3-Pin(3+Tab) Case D-61-8-SM
PDF
/
Inventory: 9084
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case D-61-8-SM
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2014
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY, LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 1.5mA @ 80V
Voltage - Forward (Vf) (Max) @ If 810mV @ 40A
Forward Current 80A
Operating Temperature - Junction -55°C~175°C
Application HIGH POWER
Max Reverse Voltage (DC) 80V
Average Rectified Current 40A
Number of Phases 1
Peak Reverse Current 1.5mA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 7kA
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status ROHS3 Compliant
