VS-43CTT100
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers 40 Amp 100 Volt Submicron Trench
PDF
/
Inventory: 5146
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 4.82mm
Length 10.66mm
Height 9.02mm
Technical
Max Forward Surge Current (Ifsm) 900A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 900A
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Reverse Current 150μA
Average Rectified Current 20A
Max Reverse Voltage (DC) 100V
Forward Voltage 630mV
Current - Average Rectified (Io) 20A
Voltage - DC Reverse (Vr) (Max) 100V
Max Surge Current 900A
Operating Temperature - Junction 175°C Max
Max Reverse Leakage Current 150μA
Forward Current 40A
Voltage - Forward (Vf) (Max) @ If 980mV @ 40A
Current - Reverse Leakage @ Vr 1mA @ 100V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2012
Packaging Tube
Physical
Supplier Device Package TO-220AB
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
