VIT3060C-M3/4W
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Schottky 60V 30A 3-Pin(3+Tab) TO-262AA Tube
PDF
/
Inventory: 3829
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 170A
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Reverse Current 1.2mA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 60V
Application EFFICIENCY
Operating Temperature - Junction -55°C~150°C
Forward Current 30A
Voltage - Forward (Vf) (Max) @ If 700mV @ 15A
Current - Reverse Leakage @ Vr 1.2mA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, TMBS?
Published 2016
Packaging Tube
Physical
Diode Element Material SILICON
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
