VFT3080C-M3/4W
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack, Isolated Tab
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Schottky 80V 30A 3-Pin(3+Tab) ITO-220AB Tube
PDF
/
Inventory: 1668
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Published 2016
Series TMBS?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Packaging Tube
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 150A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 80V
Peak Reverse Current 700μA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 80V
Application EFFICIENCY
Operating Temperature - Junction -55°C~150°C
Forward Current 30A
Voltage - Forward (Vf) (Max) @ If 820mV @ 15A
Current - Reverse Leakage @ Vr 700μA @ 80V
Diode Type Schottky
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack, Isolated Tab
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
Compliance
RoHS Status ROHS3 Compliant
