VB20200C-E3/4W
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers 20 Amp 200 Volt Dual TrenchMOS
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6093
≥1 USD $1.6093
≥10 USD $1.3205
≥100 USD $1.27965
≥500 USD $1.23785
≥1000 USD $1.197
Inventory: 12605
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 120A
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 150μA
Average Rectified Current 10A
Max Reverse Voltage (DC) 200V
Forward Voltage 1.6V
Current - Average Rectified (Io) 10A
Voltage - DC Reverse (Vr) (Max) 200V
Max Surge Current 120A
Operating Temperature - Junction -40°C~150°C
Max Reverse Leakage Current 150μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 1.6V @ 10A
Current - Reverse Leakage @ Vr 150μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TMBS?
Published 2011
Packaging Tube
Physical
Supplier Device Package TO-263AB
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
