V30150C-E3/4W
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 150V TO220
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 1179
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.7mm
Length 10.54mm
Height 15.32mm
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 140A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 150V
Peak Reverse Current 200μA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 150V
Forward Voltage 1.36V
Application EFFICIENCY
Max Surge Current 150A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 800μA
Forward Current 30A
Voltage - Forward (Vf) (Max) @ If 1.36V @ 15A
Current - Reverse Leakage @ Vr 200μA @ 150V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Terminal Position SINGLE
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series TMBS?
Published 2011
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
