UH4PCC-M3/87A
RoHS
RoHS compliant
RoHS compliantPackage TO-277, 3-PowerDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode Switching 150V 4A 3-Pin SMPC T/R
PDF
/
Inventory: 6400
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-277, 3-PowerDFN
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2013
Series eSMP?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number UH4PCC
Pin Count 3
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 150V
Voltage - Forward (Vf) (Max) @ If 1.05V @ 2A
Forward Current 4A
Operating Temperature - Junction -55°C~175°C
Max Surge Current 40A
Output Current-Max 2A
Application ULTRA FAST RECOVERY
Max Reverse Voltage (DC) 150V
Average Rectified Current 2A
Number of Phases 1
Reverse Recovery Time 25 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 150V
JEDEC-95 Code TO-277A
Peak Non-Repetitive Surge Current 40A
Reverse Voltage 150V
Diode Configuration 1 Pair Common Cathode
Recovery Time 25 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
