GSD2004C-E3-18
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Standard 1Pair Common Cathode Diode Array 1V @ 100mA 225mA 50ns 300V
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.242259
≥1 USD $0.242259
≥10 USD $0.228539
≥100 USD $0.215605
≥500 USD $0.203403
≥1000 USD $0.191887
Inventory: 1103
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 4A
Max Repetitive Reverse Voltage (Vrrm) 300V
Reverse Recovery Time 50 ns
Average Rectified Current 225mA
Max Reverse Voltage (DC) 240V
Output Current-Max 0.225A
Operating Temperature - Junction 150°C Max
Forward Current 225mA
Voltage - Forward (Vf) (Max) @ If 1V @ 100mA
Current - Reverse Leakage @ Vr 100nA @ 240V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Reference Standard AEC-Q101
Pin Count 3
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8541.10.00.70
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2017
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Weight 8.788352mg
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
