UC3611DWG4
RoHS
/
Package SOIC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 50V 16SOIC
PDF
/
Inventory: 8420
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 16
Diode Element Material SILICON
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 2
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature FREE WHEELING DIODE
Subcategory Other Diodes
Technology SCHOTTKY
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Pin Count 16
Number of Elements 4
Configuration SEPARATE, 4 ELEMENTS
Power Dissipation-Max 1W
Diode Type RECTIFIER DIODE
Current - Output 3A
Forward Current 3A
Max Reverse Leakage Current 100μA
Application EFFICIENCY
Forward Voltage 1.2V
Max Reverse Voltage (DC) 50V
Average Rectified Current 3A
Number of Phases 1
Reverse Recovery Time 20 ns
Peak Reverse Current 100μA
Max Repetitive Reverse Voltage (Vrrm) 50V
Recovery Time 20 ns
Reverse Test Voltage 40V
Dimensions
Height 2.35mm
Length 10.28mm
Width 7.52mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
