STTH61R04TV1
RoHS
RoHS compliant
RoHS compliantPackage ISOTOP
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 400V 30A ISOTOP
PDF
/
Inventory: 9293
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case ISOTOP
Number of Pins 4
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature LOW LEAKAGE CURRENT
Subcategory Other Diodes
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH61
Pin Count 4
Qualification Status Not Qualified
Number of Elements 2
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 15μA @ 400V
Voltage - Forward (Vf) (Max) @ If 1.45V @ 30A
Case Connection ISOLATED
Max Surge Current 350A
Application ULTRA FAST RECOVERY
Forward Voltage 1.45V
Max Reverse Voltage (DC) 400V
Average Rectified Current 30A
Number of Phases 1
Reverse Recovery Time 65 ns
Peak Reverse Current 15μA
Peak Non-Repetitive Surge Current 350A
Reverse Voltage 400V
Diode Configuration 2 Independent
Recovery Time 65 ns
Compliance
RoHS Status ROHS3 Compliant
