STTH6110TV2
RoHS
RoHS compliant
RoHS compliantPackage ISOTOP
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Rectifier Diode, Dual Isolated, 1 Kv, 30 A, 320 Mv, 42 Ns, 240 A Rohs Compliant: Yes
PDF
/
Buying Options
Total Price: USD $17.57
Unit Price: USD $17.5736
≥1 USD $17.5736
≥10 USD $15.61296
≥100 USD $13.6554
≥500 USD $11.652643
Inventory: 127
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Recovery Time 100 ns
Max Forward Surge Current (Ifsm) 240A
Diode Configuration 2 Independent
Reverse Voltage 1kV
Peak Non-Repetitive Surge Current 240A
Max Repetitive Reverse Voltage (Vrrm) 1kV
Peak Reverse Current 15μA
Reverse Recovery Time 100 ns
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 1kV
Forward Voltage 320mV
Voltage - DC Reverse (Vr) (Max) 1000V
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Max Surge Current 240A
Operating Temperature - Junction 150°C Max
Forward Current 30A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 2V @ 30A
Output Current 60A
Current - Reverse Leakage @ Vr 15μA @ 1000V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Dual
Number of Elements 2
Pin Count 4
Base Part Number STTH61
Current Rating 60A
Terminal Form UNSPECIFIED
Terminal Position UPPER
Voltage - Rated DC 1kV
Subcategory Other Diodes
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, HIGH RELIABILITY
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Nickel (Ni)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case ISOTOP
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 31 Weeks
